Interwork between M3UA and M2PA

Does your signaling node only supports M2PA? and you want to connect to another signaling node that supports M3UA? There may be a case when you own a product that supports only one of the SIGTRAN signaling protocols, either M3UA or M2PA. However, to implement a new signaling connection or service, your node needs to communicate with another node that doesn’t support the same SIGTRAN signaling protocol. In such a case, a gateway is needed that can convert M3UA to M2PA and vice-versa.

The M2PA protocol operates at Layer 2 just like MTP2 protocol of the SS7 stack. On the other hand, M3UA protocol operates at Layer 3 just like the MTP3 protocol of the SS7 stack. Due to the difference of the layers at which these protocols operate, the conversion is not direct and becomes complicated as lot of routing information is embedded in the signaling messages.

At Shabd Communications, our Evolved STP solution is an advance IP based Signaling Transfer Point (STP), that among its several advanced capabilities also supports inter-working between M2PA and M3UA protocol. Some other capabilities of our Evolved STP solution are:-

• Modern Signaling Transfer Point node for the SIGTRAN based signaling networks.
• Support for both M3UA and M2PA, and support for interwork between them.
• Reduce the complexity of the network through central configurations in the SIGTRAN-STP
• Connect both internal and external nodes through the same SIGTRAN-STP, hiding the internal signaling network from direct exposure.
• Flexibility to assign more than one point code to connect to both national network and international networks at the same time
• Centralize the ease of management of your Global Title Translations
• Modular design ensuring carrier grade performance
• Small footprint for installation; use virtual machines or bare metal machines based on your data center setup
• Simple and intuitive to use Command Line Interface for configurations
• Notifications for Link Status and Signaling Node reachability status changes
• Capability to inspect the 3GPP MAP level attributes and replacing them as they pass through the SIGTRAN STP
• Replace IMSI values, MSISDN values in the 3GPP MAP messages as they pass through the SIGTRAN STP to suit your network needs
• Route messages received from international networks to national networks and vice-versa
• Blacklisting of signaling messages originating from a certain PC or GT.

Our Evolved-STP product is a feature-rich solution and that can simplify your network and provide the capability to connect with other networks seamlessly.
Download Feature Sheet for the E-STP Solution or visit this page.
For more information, please contact us at sales@shabdcom.org
